The AR14J is a diesel articulating boom lift engineered for reliable access on rough-terrain jobsites. It combines a 16.09 m working height, 7.67 m horizontal outreach, and a 230 kg platform capacity to carry two occupants with tools. A tight chassis and full-height drive let operators position fast and work precisely around obstacles.
Key highlights
- Working height: 16.09 m; platform height: 14.09 m
- Horizontal outreach: 7.67 m; up-and-over: 7.56 m
- Platform size: 1.83 × 0.76 m; capacity: 230 kg (2 occupants)
- 355° turntable with 160° platform rotator for precise positioning
- 4WD with oscillating axle and 45% gradeability
- Drive speed: 6.1 km/h stowed; 0.8 km/h raised
- Deutz EU V / Tier 4f engine, 36.4 kW (48.8 hp)
Work envelope and reach
The dual-articulation boom clears obstacles up to 7.56 m and maintains stable outreach at height. Zero tailswing and compact stowed dimensions (L 6.766 m, W 2.31 m, H 2.17 m) support maneuvering in congested areas.
Traction and stability
- Permanent 4WD with oscillating axle improves traction on uneven ground
- Foam-filled rough-terrain tyres, 848 × 315 mm
- Ground clearance: 0.36 m; wheelbase: 2.059 m
Controls and protection
- Proportional joysticks for smooth lift and drive
- Platform auto-level and 160° rotator enhance positioning
- Tilt alarm with lift cut-out and overload sensing
- Descent alarm with beacon, emergency stop at platform and base
- On-board diagnostics for quick troubleshooting
Powertrain and service
- Deutz diesel engine compliant with EU V / Tier 4f
- Fuel tank: 65 L; hydraulic oil: 130 L
- Machine weight (CE/ANSI): 7,160 kg
Standard equipment
- Full-height drive; AC power to platform; platform toolbox
- Anti-crush protection; horn and hour meter
- Foam-filled non-marking tyres (RT pattern)
Typical applications
- Steel erection, cladding, and façade work
- MEP installation and commissioning
- Facilities maintenance and outdoor industrial sites
- Infrastructure and utility work where up-and-over access is required
Compliance
Meets EN 280 and ANSI 92.20 requirements.
