RENTAL OMMELIFT 2500 E SPIDER LIFT – 25.1M WORKING HEIGHT

The OMMELIFT 2500 E is a compact trailer-mounted telescopic lift available for rental, offering up to 25.1 m working height and strong outreach for maintenance, installation, and façade works. Easy to transport and quick to set up, it provides smooth proportional controls, stable hydraulic outriggers, and a practical basket for efficient work at height.

Rental OMMELIFT 2500 E Spider Lift – 25.1m Working Height

Description

The OMMELIFT 2500 E is a trailer-mounted access platform designed for safe, efficient work at height across a wide range of job sites. Its trailer format makes transportation simple, while the quick set-up concept helps teams move between locations with minimal downtime.

Built for everyday rental use, the machine focuses on operator confidence and site productivity. Proportional controls support smooth, precise positioning, and the stabilized working setup provides strong footing when working on uneven or variable ground conditions. The platform layout is practical for tools and materials, supporting typical maintenance and installation tasks.

The 2500 E is a strong fit for building maintenance, façade access, lighting and signage works, MEP installation, and general contractors who need flexible access without committing to a dedicated truck-mounted unit. Whether used indoors or outdoors (subject to site conditions), it delivers dependable access performance with straightforward operation and transport convenience.

Technical Specifications

Manufacturer name

OMMELIFT

Model number

2500 E

Equipment type

Trailer lift (telescopic)

Max. working height

25.1 m

Max. platform height

23.1 m

Max. outreach

12.6 m

Max. basket load

200 kg

Basket load at max. outreach (chart)

80 kg

Angle boom length (boom + basket)

2.0 m

Turret rotation

± 355°

Basket rotation

± 41°

Basket size (L x W x H)

1.25 x 0.8 x 1.1 m

Stabilizer pad size

Ø200 mm

Hydraulic stabilizers

Standard

Max. force

17.1 kN

Ground pressure

20.0 kg/cm²

Ground pressure with 0.4 x 0.4 m spreader plate

1.1 kg/cm²

Outrigger footprint (L x W)

4250 x 4250 mm

Power supply option

230V / 16A

Engine (petrol/diesel)

Optional

Fuel tank capacity

16 l

Generator

24 V / 22 A

Battery pack

24V/200Ah/5h

Charger

24 V / 30 A

Double charger system

Optional

Electric descent

Optional

Hybrid engine rating (if hybrid version)

14 kW / 18.8 hp

Self-propulsion with hydraulic engagement of traction rollers

Standard

Gradeability

14% / 8°

Ground to tire clearance at max. set-up

Min. 170 mm (5.9% / 3.4°)

Total weight (2500 E)

3000 kg

Total weight (2500 EB)

3060 kg

Total weight (2500 EBD)

3180 kg

Controls

Proportional

Flush basket mount

Standard

Electric power outlet in basket

Standard

Tool trays in basket

Standard

Transport length

8410 mm

Transport width

1710 mm

Transport height

2110 mm

Ratings

0.00 ( 0 )

Comments 0

No comments yet.

Pricing Information

Rental Rate

SAR 26,000.00 per month
Availability: In Stock (1)
Delivery time: 3–9 days
